|The parts between the shoes was what I needed to finally fix the brakes. This is the old shoes (the ones that were left) before I changed them. Took a couple pictures in case I forgot how to put it back together.|
Then when I had the hardware kit and went to install the shoes I found there was another missing part. Part of the mechanism that pushes the shoes apart was missing. Yesterday I went to see my neighbor because he has a wrecked Expedition. I got the parts I needed and cleaned them up and they were froze in place with rust and crud. A little Never-Seize on the pin the parts pivot on and I got everything installed. Now the brakes lock up and will hold the truck. The main reason I wanted to fix the parking brakes is the truck is a stick and with over 230K miles the engine probably doesn't have enough compression to hold the truck by putting it in gear on a hill with any kind of slope.
